Specification |
GRV-OACI-12 |
GRV-OACIS-12 |
GRV-OAC-12 |
GRV-OACS-12 |
Line Voltage |
12–250 VAC |
12–250 VAC |
12–250 VAC |
12–250 VAC |
Current Rating (per channel) |
0.5 A |
0.5 A |
0.5 A |
0.5 A |
Recommended Max. Fuse (fast) or Circuit Breaker |
2 A 250 VAC / channel, 6 A 250 VAC common |
2 A 250 VAC / channel, 6 A 250 VAC common |
2 A 250 VAC / channel, 6 A 250 VAC common |
2 A 250 VAC / channel, 6 A 250 VAC common |
Minimum Load Current |
20 mA |
20 mA |
20 mA |
20 mA |
Output Voltage Drop |
1 V |
1 V |
1 V |
1 V |
Off-state Leakage at Nominal Voltage - 60 Hz |
1.25 mA @240 VAC 0.7 mA @120 VAC |
1.25 mA @240 VAC 0.7 mA @120 VAC |
1.25 mA @240 VAC 0.7 mA @120 VAC |
1.25 mA @240 VAC 0.7 mA @120 VAC |
Peak Blocking Voltage |
500 V |
500 V |
500 V |
500 V |
Operating Frequency |
40 to 60 Hz, 400 Hz |
40 to 60 Hz, 400 Hz |
40 to 60 Hz, 400 Hz |
40 to 60 Hz, 400 Hz |
Turn-on Time |
≤ 1/2 cycle (zero crossing) |
≤ 1/2 cycle (zero crossing) |
≤ 1/2 cycle (zero crossing) |
≤ 1/2 cycle (zero crossing) |
Turn-off Time |
≤ 1/2 cycle (zero crossing) |
≤ 1/2 cycle (zero crossing) |
≤ 1/2 cycle (zero crossing) |
≤ 1/2 cycle (zero crossing) |
TPO Period (min, max, resolution) |
0.1 seconds, 429496.7296 seconds, 0.001 seconds |
N/A |
0.1 seconds, 429496.7296 seconds, 0.001 seconds |
N/A |
Problem Indication |
open circuit |
none |
open circuit |
none |
Isolation (field-to-logic) |
300 V working, 1500 V transient (1 minute) |
300 V working, 1500 V transient (1 minute) |
300 V working, 1500 V transient (1 minute) |
300 V working, 1500 V transient (1 minute) |
Isolation (channel-to-channel) |
300 V working |
300 V working |
NONE |
NONE |
Number of Channels |
12 |
12 |
12 |
12 |
Chassis Power Consumption |
1.3 W |
1.3 W |
1.3 W |
1.3 W |
Minimum GRV-EPIC-PR1 Firmware Version |
1.0.0 |
1.0.0 |
1.0.0 |
1.0.0 |
Minimum PAC Project Version |
10.0000 |
10.0000 |
10.0000 |
10.0000 |
Minimum Library Package for CODESYS Version |
1.0.0.0 |
1.0.0.0 |
1.0.0.0 |
1.0.0.0 |
Wire Size |
28–14 AWG |
28–14 AWG |
28–14 AWG |
28–14 AWG |
Torque, connector screw |
2.5 in-lb (0.28 N-m) |
2.5 in-lb (0.28 N-m) |
2.5 in-lb (0.28 N-m) |
2.5 in-lb (0.28 N-m) |
Torque, hold-down screw |
3.5 in-lb (0.4 N-m) |
3.5 in-lb (0.4 N-m) |
3.5 in-lb (0.4 N-m) |
3.5 in-lb (0.4 N-m) |
Temperature (operating) |
-20 °C to +70 °C |
-20 °C to +70 °C |
-20 °C to +70 °C |
-20 °C to +70 °C |
Temperature (storage) |
-40 °C to +85 °C |
-40 °C to +85 °C |
-40 °C to +85 °C |
-40 °C to +85 °C |
Relative Humidity (non-condensing) |
5–95% |
5–95% |
5–95% |
5–95% |
Agency Approvals |
UL/cUL(Class 1 Div. 2)a; CE, ATEX (Category 3, Zone 2), RoHS; DFARS; CB Scheme; UKCA |
Warranty |
Lifetime |
a For use in hazardous locations, equipment must be mounted in an enclosure that meets the requirements of the National Electrical Code, ANSI/NFPA 70, and ANSI/ISA-61010-1 (82.02.01). |
