G4IDC5B
Hover over image to zoom in

G4IDC5B

$27.50 (USA and Canada only)

Availability: In stock
G4 DC Input 4-16 VDC, 5VDC Logic High Speed

Production Specification

G4 I/O family

The G4IDC5B is a digital DC input module with an input voltage range of 4-16 VDC/VAC, requiring a typical logic voltage of 5 VDC. This module is compatible with Opto 22 brains.

This module offers higher speed and is designed with filtering on the input and a hysteresis amplifier, providing high noise rejection and transient-free, "clean" switching.

Opto 22’s G4 DC input modules are used to detect on/off DC voltage levels. Each module provides up to 4000 volts (transient) of optical isolation between field inputs and the logic output of the circuit. Typical applications for DC input modules include sensing the presence or absence of voltage and sensing contact closure from sources such as proximity switches, limit switches, selector switches, push buttons, photoelectric switches, and TTL-compatible devices.




Units

G4IDC5*

G4IDC5B

G4IDC5D*

G4IDC5G*

Input voltage range

VDC
VAC

10–32
12–32

4–16
4–16

2.5–28

35–60
35–60

Key feature



Higher speed

High speed

Input current at maximum line

mA

25

45

30

6

Isolation, input-to-output (transient):
1 ms
1 minute



V
V



4000
1500



4000
1500



4000
1500



4000
1500

Turn-on time

ms

5

0.05

1

10

Turn-off time

ms

5

0.1

1.5

10

Input allowed for off-state

mA, V

1, 3

0.7, 1

0.2, 1

0.7, 7

Nominal output supply voltage

VDC

5

5

5

5

Output supply voltage range

VDC

4.5–6

4.5–6

4.5–6

4.5–6

Output supply current at
nominal logic voltage

mA

12

12

12

12

Input resistance (R1 in schematic)

ohms

1.5 K

300

900

10 K

Control resistance (Rc in schematic)

ohms

220

220

470

220

Output voltage drop

V @ 50 mA

0.4

0.4

0.4

0.4

Output current (sinking)

mA

50

50

50

50

Output leakage with no input

microamps @ 30 VDC

100

100

10

100

Transistor

V breakdown

30

30

30

30

Temperature:
Operating
Storage



°C
°C



-30 to +70
-30 to +85



-30 to +70
-30 to +85



-30 to +70
-30 to +85



-30 to +70
-30 to +85

Agency Approvals   UL, CE, CSA; UKCA UL, CE, CSA; UKCA UL, CE, CSA; UKCA UL, CE, CSA, RoHS; UKCA
* Compatible with Raspberry Pi

G4 Digital DC Input Modules Data Sheet
