1 “Mixed” means the rack can hold analog, digital, and serial modules. Most Ethernet-based I/O processors handle all these types of modules; other processors do not. See the processor’s data sheet for details.
2 Power requirements shown are for a rack, a processor, and a full load of 2-channel analog modules (for the SNAP-D64RS, a full load of 4-channel digital modules). Power requirements for other SNAP modules are higher. See module data sheets.
3 “I/O Processor” means a SNAP brain or on-the-rack controller.
4 Four-channel SNAP digital modules can be used in positions 0–7 only.
5 Manufacturer’s part number (not available through Opto 22).
6 Agency Approvals include: FM Approved, UL, CE, RoHS, DFARS; UKCA
7 Agency Approvals include: FM Approved, CE, RoHS, DFARS; UKCA
