$502.00 (USA and Canada only)
Input Range
0 to 250 V RMS AC/DC
Input Over Range
To 275 V
Input Resistance
1 megohms
Accuracy
±0.2 V and ±0.2% reading
Resolution
10 mV
DC Reversal
± 0.2 V (0.08%)
Input Response Time (Step Change)
63.2% (158 V) in 50 ms 99% (248 V) in 75 ms
Data Freshness
0.025 s
DC Common Mode Rejection
>-120 dB
AC Common Mode Rejection
>-120 dB @ 60 Hz
Maximum Operating Voltage Between Channels Common Mode Voltage
250 V 250 V
Isolation: Optical
4000 V
Isolation: Transformer
1500 V
Isolation: Channel to Channel
250 V continuous (1500 V transient)
Power Requirements
5 VDC (±0.15 V) at 200 mA
Ambient Temperature: Operating Storage
-20 °C to 70 °C -40 °C to 85 °C
Humidity
5-95%, non-condensing
Torque, hold-down screws
Not to exceed 1 in-lb (0.11 N-m)
Torque, connector screws
5.22 in-lb (0.59 N-m)
Wire size range
22 to 14 AWG
Agency Approvals
CE, RoHS, DFARS
Warranty
Lifetime
The isolated analog input modules described in this document are part of Opto 22's SNAP PAC System. They provide optical isolation, transformer isolation, and channel-to-channel isolation. This data sheet covers the following part numbers:
This document lists and describes all current Opto 22 SNAP PAC System part numbers, including PAC Project software, SNAP PAC controllers, and SNAP I/O modules of all kinds. SNAP PAC mounting racks and SNAP power supplies are also listed.
This document is a statement of compliance with the EU Directive 2015/863/EU, Restriction of Hazardous Substances (RoHS 3). This document lists Opto 22 products that comply with the substance restrictions of the RoHS 3 directive.
This document lists all Opto 22 part numbers that have the Underwriters Laboratory (UL) approval.
This document is the Manufacturer's Declaration for the listed products as mentioned in the attachment - to which this confirmation refers - that they are in accordance with the mentioned European, international and/or national standards and regulations.
This CAD file includes drawings that apply to most SNAP analog and digital I/O modules.
This overview describes the four integrated components of the SNAP PAC system: software, controllers, brains and I/O. This hardware and software system is designed for industrial control, remote monitoring and data acquisition.
A quick overview on securing a SNAP Module to a SNAP rack.
A quick overview on removing a SNAP module.
What's the difference between accuracy and resolution in analog I/O specifications? Try your own specs in the calculator.
