PC-PAMUX-SDK

Availability: Call for Availability
PAMUX Systems SDK for PCI Adapter Cards

Please call (800) 321-6786 to order.

PC-PAMUX-SDK

Production Specification

Software developer toolkit for high-speed control of multiple digital and/or analog I/O points, using a brain (I/O processor) and the Pamux protocol.

The SDK requires a PCI-AC51 or a PCIe-AC51 adapter card and one of the following brains: Compatible systems: Both 64- and 32-bit versions of Windows® 10 Professional, Windows 8.1 Professional, and Windows 7 Professional.

For a system diagram and compatible I/O, see the PC-Based I/O Control Overview.

The SDK contains sample applications with source code, Windows drivers, and user documentation. It works with .NET platform languages including C#® and VB.NET®, and supports both 64-bit and 32-bit versions of:

  • Windows® 10 Professional
  • Windows 8.1 Professional
  • Windows 7 Professional

Adapter card compatibility:

  • PCI-AC51
  • PCIe-AC51

PC-Based I/O Overview

This document shows examples of system architecture for PC-based I/O control systems and lists Opto 22 products that work together for PC-based control. System examples include:

- Ethernet systems using SoftPAC, a software-based programmable automation controller programmed with PAC Control
- Ethernet systems using the OptoMMP protocol
- Direct control of I/O using no I/O processor (no brain)
- Serial control using a brain and the mistic or Optomux protocol
- High-speed control using the Pamux protocol

README for Pamux Systems SDK for PCI Adapter Cards

This README file lists the changes made to the Pamux Systems SDK for PCI Adapter Cards.

PCIe-AC51 Adapter Card Quick Start

The PCIe-AC51 is a high-speed adapter card designed to link the Pamux® bus to PCI Express-compatible computers. This quick start shows you how to install the card and the PAMUX Systems SDK software that comes with it.

PCI-AC51 Adapter Card Quick Start

The PCI-AC51 is a high-speed adapter card designed to link Opto 22 I/O to PCI-compatible computers for PC-based control using the Pamux protocol. This quick start shows you how to install the adapter card and the PAMUX Systems SDK that comes with it.

PCI-AC51 and PCIe-AC51 User's Guide

The PCI-AC51 and PCIe-AC51 are high-speed adapter cards designed to link the Pamux® bus to PCI-compatible or PCI Express-compatible computers.

  • The PCI-AC51 is compatible with a standard PCI bus.
  • The PCIe-AC51 is compatible with PCI Express.
The Pamux Systems SDK is included with purchase of either card. This user's guide covers installation and use of both cards and the SDK.

NOTE: These cards replace the older PCI-AC28.
