PAC-INT-BAC-IP

Availability: Obsolete
OBSOLETE BACnet/IP Integration Kit for PAC Control

Production Specification

*** NOTE: This integration kit is obsolete. The last available version has been moved to our FTP site (ftp://ftp.opto22.com). ***

BACnet/IP Integration Kit for PAC Control™ (Part # PAC-INT-BAC-IP) enables Opto 22 PAC systems equipped with a PAC controller running a PAC Control strategy to communicate with devices on a BACnet/IP network. The integration kit also works with strategies running on a SoftPAC™ software-based controller.

The integration kit contains BACnet_IP_Protocol, BACnet_Master, and VAV_Poll_Example charts. The kit is a full BACnet/IP master with slave functions.

*** NOTE: This integration kit is obsolete. The last available version has been moved to our FTP site (ftp://ftp.opto22.com). ***
In addition to the integration kit, you’ll need:
  • A PC with PAC Control R9.4a or higher (Basic or Pro)
  • An Ethernet-connected PAC controller with PAC firmware R9.4a or higher, or an Ethernet-connected PC running SoftPAC R9.4a or higher

README for BACnet/IP Integration Kit for PAC Control

*** NOTE: ​The BACnet/IP Integration Kit is obsolete. This document remains on our website for reference. ***

Latest Readme for BACnet/IP Integration Kit for PAC Control.

This Readme provides information on new features, enhancements, and bug fixes.

BACnet/IP Integration Kit for PAC Control Guide

*** NOTE: ​The BACnet/IP Integration Kit is obsolete. This document remains on our website for reference. ***

The BACnet/IP Integration Kit for PAC Control™ (Part # PAC-INT-BAC-IP) enables Opto 22 PAC systems equipped with SNAP PAC controller running a PAC Control strategy to communication with devices on a BACnet/IP network. The integration kit also works with strategies running on a SoftPAC™ software-based controller.

This guide describes the integration kit and how to use it.
