$243.00 (USA and Canada only)
DA4
DA4T
DA5
DA6
DA7
DA7T
Output Voltage
0 to 5 VDC
0 to 10 VDC
-0 to +5 VDC
-10 to +10 VDC
Accuracy
±5 mV
±10 mV
±20 mV
Power Requirements
20 mA at +15 (+/- 0.25) VDC 10 mA at -15 (+/- 0.25) VDC
35 mA at +15 (+/- 0.25) VDC 35 mA at -15 (+/- 0.25) VDC
Output Current DA4, DA5, DA6, DA7 DA4T, DA7T
70 mA 25 mA
Output Response Time
Full-scale step change in 3 ms
Resolution
12 bits
Isolation Input-to-Output Input-to-Analog Supply
4,000 Vrms (Transient) 4,000 Vrms
Temperature Operating Storage
0 °C to 70 °C - 25 °C to 85 °C
The voltage output analog module provides a single channel of optically-isolated digital-to-voltage conversion.This data sheet provides information about these standard voltage output modules:
