GROOV-SVR-WIN-BASE
Hover over image to zoom in

GROOV-SVR-WIN-BASE

$995.00 (USA and Canada only)

Availability: In stock
groov Server for Windows

Production Specification

groov Server for Windows lets you serve groov View, Opto 22’s web-based operator interface tool, from a Microsoft Windows PC.
(NOTE: If you are serving groov View from a groov EPIC processor, you do not need to purchase this product. groov View is included with your purchase of an EPIC.)

groov View gives you visualization into your system with an HMI that is simple, mobile, and connects easily to automation systems, software, databases, and devices of all kinds.

You build your groov View interface—your own custom application—using any computer with a web browser (Chrome, Firefox, Safari, IE10). No programming or coding is required. You can mix devices, equipment, and data from different sources in the same interface if you wish. There are no user or tag limits. The pages you build are served to authorized users through groov Server for Windows.

The interface you build can be used on any brand computer or device with a web browser—even a web-enabled HDTV. Or you can view the same interface on an Apple or Android mobile device with the free groov View app.

Try groov View for free! Download the free trial and see what you can do.

groov View includes trending, events, and user notifications. You control authorized users (both human and software) and their credentials.

GROOV-SVR-WIN-BASE is installed on a Microsoft Windows computer (see Specifications for details) and runs as a service. The groov View software is stored and served on the Windows PC.

GROOV-SVR-WIN-BASE provides a groov View license, which lets you monitor and control one or more of the following:

  • Modbus/TCP devices
  • Opto 22 groov EPIC processors and SNAP PAC controllers (SNAP PAC R-series, S-series, and SoftPAC)
  • Opto 22 SNAP PAC I/O units (with an R-series rack-mounted controller or an EB-series brain)
  • groov Data Stores (databases, cloud services, and APIs can write data to or read data from Data Stores)
  • OptoEMU Sensor energy monitoring units (obsolete)

No intermediary servers or protocol converters are required.

Buying GROOV-SVR-WIN-BASE and obtaining software. You can purchase groov Server for Windows by adding it to your cart here, by calling us at 800-321-6786, or by buying from your local OptoDistributor. You'll then receive an email or certificate with instructions to download and license the software from activate.groov.com.

Price includes groov Server for Windows, groov View software, and one year of updates. Maintenance renewal for successive years is free and required for updates after the first year. Product Support is free.

For more information on groov EPIC, see groov EPIC System.

NOTE: If you have an older groov Server that limits your use of an external OPC UA server, log into manage.groov.com and click the Manage button. Find your groov Server in the list and click the Manage button next to it. Install the latest version of groov View and also download and install the license file.

To build operator interfaces with groov you’ll need:

- Any computer with a web browser. (This can be the same computer where groov Server is installed, or a separate computer. The computer used to build interfaces does not have to be a Windows PC.)

To install and run groov Server you’ll need:

  • A PC on the same network as your SNAP PAC controller, with one of the following Microsoft® operating systems:
    • Windows® 11 Professional (32-bit and 64-bit)
    • Windows 10 Professional (32-bit and 64-bit)
    • Windows Server 2019
    • Windows Server 2016
    • Windows Server 2012 and 2012 R2
NOTE: .NET Framework 3.5 or greater is required for all operating systems.
  • A minimum of 250 MB available disk space to install groov Server. Additional disk space is required to create projects. (Projects may be created on this PC or on another computer.)
